ESA VT50 - PC <-> VT Connection

CHAPTER 31
Communication ports
405.1200.037.2 - Rel.: 2.21 of 25/02/2008
31-12
PC <-> VT
connection
To transfer the communication firmware, the communication driver and the
project the VT must be connected to the PC (see Software Manual) and can
be done using either Serial or Modem.
The cable required to make the connection is illustrated below.
RS232
Modem
3
2
5
7
8
6
4
TxD
RxD
GND
RTS
CTS
DSR
DTR
3
2
7
4
5
15
18
25
RxD
TxD
GND
RTS
CTS
PC side
9 pin female
VT side
25 pin male
Max. 15 m.
CVCOM11102
