ESA VT50 - Ethernet Series Rear View

CHAPTER 28
Video terminal VT595W
405.1200.037.2 - Rel.: 2.21 of 25/02/2008
28-12
Ethernet
series rear
view
Position Function
A Power supply connector
B LPT port for connecting printer
C MSP serial port for communicating with PLC/PC
D
Ethernet network 10/100Mbit RJ45 (For the diagnostic mode of
the LEDs see “Chapter 31 -> Ethernet port“)
A
DC
B
