CHAPTER 14
Video terminal VT155W
405.1200.037.2 - Rel.: 2.21 of 25/02/2008
14-22
mask will appear
The choice should be according to the speed you intend to use for the transfer
(Slow=9600bit/sec or Fast=38400bit/sec), touch the relevant on the display.
The VT is now ready to receive (see Software Manual for the transfer).
Information
relating to
driver
After the project has been transferred, the VT can make available informa-
tion relating to what has been loaded. The information regards:
• Serial ports present
• The name of the driver loaded
• The version of the driver loaded
• Network address of the VT
• Last error to have occurred
To acquire this information carry out the following operations:
• Be situated in any page of the project
• Press two diagonally opposed angles that are free of any settable objects
or buttons (at least one angle must be free)
and you will see
VT155W TRANSFER PAGE
Main BOOT and RAM check : OK
Main FIRMWARE check : OK
SELECT:
SLOW FAST
