The choice should be according to the speed you intend to use for the trans-
fer (Slow=9600bit/sec or Fast=38400bit/sec), touch the relevant on the
display. The VT is now ready to receive (see Software Manual for the trans-
fer).
Information
relating to
driver
After the project has been transferred, the VT can make available informa-
tion relating to what has been loaded. The information regards:
• Serial ports present
• The name of the driver loaded
• The version of the driver loaded
• Network address of the VT
• Last error to have occurred
To acquire this information carry out the following operations:
• Be situated in any page of the project
• Press two diagonally opposed angles that are free of any settable objects
or buttons (at least one angle must be free)
VT525W TRANSFER PAGE
Main BOOT and RAM check : OK
Main FIRMWARE check : OK
SELECT:
SLOW FAST
To Next Page
Loading...
