CHAPTER 6
Video terminal VT150W
405.1200.037.2 - Rel.: 2.21 of 25/02/2008
6-10
Customizing
label
The total thickness of the label must not exceed 125µm (microme-
ters). Do not use either stiff materials or glues.
Before starting to insert the customized label, see
“Chapter 29 ->
Inserting customized labels“
.
Position Function - Dimensions L x H (mm)
1 ESA Logo - 65 x 12
2 VT Model - 65 x 12
3 F-key customization F - 116 x 16
3
2
1
