ESA VT50 - Status Area for Printer

CHAPTER 38
Data exchange area
405.1200.037.2 - Rel.: 2.21 of 25/02/2008
38-26
Status area for
printer
This area consists of 2 words (numbered from 0 to 1).
NO. OF WORD NAME OF WORD
0 STATUS WORD for ASP
1 STATUS WORD for LPT
Table 38.26: Meaning of the Bits of the Status Word for ASP
WORD 0
MEANING OF THE
BIT
NUMBER OF THE BIT
VT
50
VT
60
VT
130
W
VT
150
W
VT
160
W
VT
170
W
VT
190
W
VT
300
W
VT
310
W
VT
320
W
VT
330
W
VT
155
W
VT
185
W
VT
505
H
VT
505
W
VT
515
W
VT
525
H
VT
525
W
VT
555
W
VT
56x
W
VT
575
W
VT
580
W
VT
585
W
VT
585
WB
VT
595
W
STAMPANTE NOT
ON LINE
Status 1 when one of
the bits from 3 to 8 is
set at 1.
n.p.n.p.0n.p.n.p.00000000n.p.n.p.n.p.000000000
TIMEOUT
Status 1 when the pr inter
is OFFLINE, not con-
nected, lacks paper or
when there is any com-
munication problem fol-
low the command to
print.
n.p.n.p.1n.p.n.p.11111111n.p.n.p.n.p.111111111
-- n.p. n.p. -- n.p. n.p. -- -- -- -- -- -- -- -- n.p. n.p. n.p. -- -- -- -- -- -- -- -- --
REPORT PRINTING
IN PROGRESS
Status 1 as long as
the function lasts
n.p.n.p.3n.p.n.p.33333333n.p.n.p.n.p.333333333
DIRECT PRINTING
OF THE INFORMA-
TION MESSAGE IN
PROGRESS
Status 1 as long as
the function lasts
n.p.n.p.4n.p.n.p.44444444n.p.n.p.n.p.444444444
DIRECT PRINTING
OF THE ISA
ALARME IN
PROGRESS
Status 1 as long as
the function lasts
n.p.n.p.5n.p.n.p.55555555n.p.n.p.n.p.555555555
PRINTING OF
ALARM HISTORY
BUFFER IN
PROGRESS
Status 1 as long as
the function lasts
n.p.n.p.6n.p.n.p.66666666n.p.n.p.n.p.666666666
HARDCOPY IN
PROGRESS
Status 1 as long as
the function lasts
n.p.n.p.7n.p.n.p.77777777n.p.n.p.n.p.777777777
FORM-FEED IN
PROGRESS
Status 1 as long as
the function lasts
n.p.n.p.8n.p.n.p.88888888n.p.n.p.n.p.888888888
-- : non used n.p. : not present
