ESA VT50 - Telemecanique Plc

CHAPTER 41
Connection cables
405.1200.037.2 - Rel.: 2.21 of 25/02/2008
41-70
TELEMECANIQUE PLC
16
18
470 Ω
1/4 W
15
4
5
RTS
CTS
7
25
GND
TxRx-
22
22 TxRx+
10
TxRx+
TxRx-
220 Ω
1/4 W
7
470 Ω
1/4 W
12
25 GND
VT side
D-Sub
25 pin male
PLC side
D-Sub
25 pin male
Order code:
CVPLC11002
TSX47 UNITELWAY module TSXSCM21
Port Ch.1
(RS485)
Point to point connection.
Address of VT: 4...31
Address of PLC (N): 0, 4...31
Address of PLC module: 0...254
(See “Chapter 41 -> Connecting the cable shield“)
7
+20mA
+Tx
14
9
+20mA 15
+Rx 18
-Rx
-Tx
25
11
CTS
4
5
GND
RTS
+R
x
6
-Rx
1
5+Tx
9-Tx
VT side
D-Sub
25 pin male
PLC side
D-Sub
9 pin male
Order code:
CVPLC11102
TSX17/20 using CVPLC1Q102 translator
(Current loop)
(See “Chapter 41 -> Connecting the cable shield“)
SHD5
-Rx
+Rx
25
18
-Tx
+Tx
11
9
TxD-
RxD-
6
7
TxD+
RxD+
4
2
+12V
0V
9
8
RTS
CTS
4
5
VT side (Passive)
D-Sub
25 pin male
PLC side (Active)
D-Sub
9 pin male
Order code:
CVPLC11202
TSX47 - 67 - 87 - 107
(Current loop)
NOTE: The max length of the cable depends on which version of the Telemeca-
nique CPU hardware is being used. With versions of hardware coded lower than
V3 (E.g. CPU 47/11, 47/20) the length of the cable is limited to 3 meters given that
the serial port of the CPU is not optoisolated !!! In this case, whenever you need
to create a cable longer than 3 meters, it is advisable the employ a Telemeca-
nique device like XBT Z 9011 or 9012 to guarantee the galvanic isolation of the
serial line. Failure to adopt such a device can cause damage to the CPU’s serial
port !!!
If the CPU is of a hardware version coded higher than V3 (E.g.. CPU 47/411,
47/425 etc.) the max length of the cable relates to the particular characteristics of
the interface in Current loop (max 1000 meters) even without employing the
optoisolating device mentioned above, in so far as the CPUs have an internal cir-
cuitry created to guarantee the optoisolation of the line.
(See “Chapter 41 -> Connecting the cable shield“)
See note
