ESA VT50 - Status Area for Recipes

CHAPTER 38
Data exchange area
405.1200.037.2 - Rel.: 2.21 of 25/02/2008
38-14
Status area for
recipes
This area consists of 1 word (numbered 0).
NO. OF WORD NAME OF WORD
0 STATUS WORD for RECIPES
Table 38.15: Meaning of the Bits of the Status Word for Recipes
WORD 0
MEANING OF THE BIT
NUMBER OF THE BIT
VT
50
VT
60
VT
130
W
VT
150
W
VT
160
W
VT
170
W
VT
190
W
VT
300
W
VT
310
W
VT
320
W
VT
330
W
TIMEOUT FOR RECIPE TRANSFER
Status 1 when the terminal does not respond in the
expected time
-- -- 13 -- -- 13 13 13 13 13 13
TRANSFER OVER
Status 1 when the terminal has sent all the relevant
data
-- -- 14 -- -- 14 14 14 14 14 14
TRANSFER REQUEST
Status 1 when the terminal wants to start to transfer
-- -- 15 -- -- 15 15 15 15 15 15
-- : not present
Table 38.16: Meaning of the Bits of the Status Word for Recipes
WORD 0
MEANING OF THE BIT
NUMBER OF THE BIT
VT
155
W
VT
185
W
VT
505
H
VT
505
W
VT
515
W
VT
155
W
VT
185
W
VT
505
H
VT
505
W
VT
525
H
VT
525
W
VT
555
W
VT
56x
W
VT
575
W
VT
580
W
VT
585
W
VT
585
WB
VT
595
W
TIMEOUT FOR RECIPE TRANSFER
Status 1 when the terminal does not respond in the
expected time
13 13 13 13 13 13 13 13 13 13 13 13 13 13 13 13 13 13
TRANSFER OVER
Status 1 when the terminal has sent all the relevant
data
14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14
TRANSFER REQUEST
Status 1 when the terminal wants to start to transfer
15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15
-- : not present
