ESA VT50 - CAN Series Rear View

CHAPTER 3
Video terminal VT50
405.1200.037.2 - Rel.: 2.21 of 25/02/2008
3-10
CAN series
rear view
Position Function
A Power supply connector
B ASP-8 serial port
C Trimmer for adjusting display contrast
D CAN serial port
A
B
C
D
