ESA VT50 - Danfoss Drive

CHAPTER 41
Connection cables
405.1200.037.2 - Rel.: 2.21 of 25/02/2008
41-12
DANFOSS DRIVE
16
18
470 Ω
1/4 W
15
7
25
22
10
220 Ω
1/4 W
7
470 Ω
1/4 W
4
5
RTS
CTS
GND
2
7
VCC
1
2
3
4
5
6
7
8
SHD
RxTx
RxTx
TxRx-
TxRx+
VT side
D-Sub
25 pin male
Drive side
RJ45
8 pin
Order code:
CVPLC33102
Commander SE - CTNET
(RS485)
Set parameter 41 = ANSI
Set parameter 42 = (Baud rate)
Set parameter 43 = (Address)
(See “Chapter 41 -> Connecting the cable shield“)
Front
View
16
18
470 Ω
1/4 W
15
4
5
RTS
CTS
7
25
GND
TxRx-
22
10
TxRx+
220 Ω
1/4 W
7
470 Ω
1/4 W
69 TxRx-
68 TxRx+
SHD
VT side
D-Sub
25 pin male
Order code:
NOT CODED
VLT2800/5000/6000
(RS485)
(See “Chapter 41 -> Connecting the cable shield“)
Drive side
Terminals
