ESA VT50 - Rear View

405.1200.037.2 - Rel.: 2.21 of 25/02/2008
12-11
Rear view
Position Function
A Auxiliary port for connecting optional accessories
B Trimmer for brightness control
C Power supply connector
D MSP serial port for communicating with PLC/PC
E ASP serial port for communicating with PC or other devices
F LPT port for connecting printer (Optional)
E
C
FD
A B
