CHAPTER 11
Video terminal VT310W
405.1200.037.2 - Rel.: 2.21 of 25/02/2008
11-16
• Choose the required transfer mode: MODEM if you intend to use a
modem or PC if you intend to use a serial port; press the corresponding
function
If the choose made is PC, the VT is ready to receive (see Software Manual
for transfer), if, on the other hand, you choose MODEM, the following
mask will appear
The choice should be according to the speed you intend to use for the trans-
fer (Slow=9600bit/sec or Fast=38400bit/sec), press the corresponding func-
tion . The VT is now ready to receive (see Software Manual for the
transfer).
Information
relating to
driver
After the project has been transferred, the VT can make available informa-
tion relating to what has been loaded. The information regards:
• Serial ports present
• The name of the driver loaded
• The version of the driver loaded
• Network address of the VT
• Last error to have occurred
To acquire this information carry out the following operations:
• Be situated in any page of the project
• Press twice; you will see
VT310 TRANSFER PAGE
Graphic controller BOOT check : OK
Graphic controller RAM check : OK
Graphic controller synchronization : OK
Main FIRMWARE check : NOT PRESENT
Graphic controller FIRMWARE : ERROR
F1=SLOW F2=FAST
Shift
To Next Page
