405.1200.037.2 - Rel.: 2.21 of 25/02/2008
19-3
Keyboard ▼▼
Non-customizable function keys 10
●●
User memory
Project [Bytes] 960K
●●
Data memory [Bytes] 32K (Flash EPROM)
●●
Memory for Windows ® -based fonts [Byte]
256K
●●
Memory Card for backup --
Memory Card for expansion --
Interfaces
MSP (Multi-serial port) RS232/RS422/RS485/TTY-20mA
●
2
●
1
ASP (Auxiliary serial port) RS232/RS485
ASP-15L (Auxiliary serial port) RS232/RS485
●
1-2
ASP-8 (Auxiliary serial port) RS232
ASP-9 (Auxiliary serial port) RS232
LPT parallel port Centronics
Auxiliary port Connections for accessories
Accessories
Connectable accessories See table ”Chapter 34”
●●
Clock
Clock
Hardware (with Supercapacitor - Min.72h Typically130h)
●●
Networks
Integrated
Profibus-DP
CAN Open (Optoisolated interface)
●
Ethernet 10/100Mbit RJ45
Universal Bus Connector --
Optional See table ”Chapter 34”
●●
Proprietary networks
ESA-Net
Network server
Network client
●
Code of terminal Characteristics of the terminal
VT525H 00000
VT525H 000CN
1 – Using the VTHCB card (see “Chapter 34 -> Page 9“)
2 - RS232 only
Wrapping
Type Antiflame PC/ABS halogen-free (UL94 5VA at 2.5mm)
Drop test 1 m.
Connection cable
Type Antiflame shielded cable halogen and silicone-free
Radius of curve (moving/fixed) 120mm/60mm
Conductors (number/section) 25x0,25mmq (AWG24)
System shut-down button
Positions 2 (Normal - Pushed)
Contacts 1 NC + 1 NC (NC1/NC2 + NC3/NC4)
Maximum tension 30Vdc
Maximum/minimum current 500mA/5mA
Conforms to the following standard(s) EN 60947-5-1, UL-508, CSA 22.2. No. 14)
Enabling button
Positions 3 (Normal - Pushed - Panic)
Contacts 1 NC/NO + 1 NC/NO (NC1/NO1/C1 + NC2/NO2/C2)
