• Wait a few moments until the VT displays either the following mask or
the project page
• Switch off the terminal
• Reposition J11 on pins 1-2
• Replace the back cover
• Switch on the terminal again
The calibration procedure has finished; if the calibration has be carried out
wrongly or imprecisely, repeat the procedure.
Termination of
CAN line
This paragraph applies only to the CAN series. The VT in question inte-
grates the termination resistances of the serial line (typically 120 ohms)
which can be inserted by means of a jumper (preset on 1-2, line not termi-
nated). To activate the termination:
• Make sure the device is not connected to the power supply.
• Remove the cover.
• Identify the jumper unit J14.
VT585WB TRANSFER PAGE
SELECT:
MSP ASP EXITMemoCARD
To Next Page
Loading...
