ESA VT50 - Gefran Plc

405.1200.037.2 - Rel.: 2.21 of 25/02/2008
41-45
GEFRAN PLC
16
470 Ω
1/4 W
4
5
RTS
CTS
7
25
GND
Rx+
Rx-
7
470 Ω
1/4 W
VCC
RTS+
CTS+
22
23
Tx-
23
25
12
Tx+
13
Rx-
13
21
24
Rx+
9
Tx+
Tx-
7
GND
18
15
SHD1
RTS-
CTS-
10
11
TERM24
VT side
D-Sub
25 pin male
Order code:
CVPLC09302
Series 90
Using GE FANUC CMM311 interface
(RS422)
CONFIGURATION OF CMM311:
SNP only
SNP Enable : Yes
SNP Mode : Slave
Interface : RS422 (solo port2)
Data Rate : 19200
Timeout : Long
Parity : Odd
Stop bits : 1
Flow control : None
TurnA delay : None
(See “Chapter 41 -> Connecting the cable shield“)
PLC side
D-Sub
25 pin male
RxD
TxD
RTS
CTS
GND
3
2
7
25
TxD
RxD
GND
4
3
1
2
8
4
5
15
18
RTS
CTS
1
2
3
4
5
6
7
8
SHD
VT side
D-Sub
25 pin male
PLC side
RJ45
8 pin
Max. 15 m.
Order code:
CVPLC09402
Versamax
using port 1
(RS232)
(See “Chapter 41 -> Connecting the cable shield“)
Front
View
RxD
TxD
RTS
CTS
GND
3
2
7
25
Tx
Rx
GND
15
14
12
11
13
4
5
15
18
4
5
VT side
D-Sub
25 pin male
PLC side
D-Sub
15 pin male
Order code:
CVPLC23102
Series MPS-NS
(RS232)
(See “Chapter 41 -> Connecting the cable shield“)
Max. 10 m.
