405.1200.037.2 - Rel.: 2.21 of 25/02/2008
20-17
• Wait a few moments until the VT displays either the following mask or
the project page (the page may be slightly different in its wording
depending on which series the terminal belongs to)
• Switch off the terminal
• Reposition J1 on pins 1-2
• Replace the back cover
• Switch on the terminal again
The calibration procedure has finished; if the calibration has be carried out
wrongly or imprecisely, repeat the procedure.
Termination of
CAN line
This paragraph applies only to the CAN series. The VT in question inte-
grates the termination resistances of the serial line (typically 120 ohms)
which can be inserted by means of a jumper (preset on 1-2, line not termi-
nated). To activate the termination:
• Make sure the device is not connected to the power supply.
• Remove the cover.
• Identify the jumper unit J4.
VT525W TRANSFER PAGE
Main BOOT and RAM check : OK
Main FIRMWARE check : OK
SELECT:
MSP ASP EXIT
