CHAPTER 23
Video terminal VT565W
405.1200.037.2 - Rel.: 2.21 of 25/02/2008
23-12
Preparation
for reception
The program VTWIN (see Software Manual) must be used for the transfer,
but the terminal must be set up to receive. This means carrying out the fol-
lowing steps:
• Check that the VT is off
• Check that there is a serial connection between the PC and the VT
• Switch on the VT by pressing simultaneously on two diagonally opposed
angles of the screen
and wait a moment, or, using the appropriate button (see Page 23-17),
till the VT displays the following mask
VT terminal with no Modem function:
• Choose the port you intend to use for the transfer (MSP or ASP); touch
the relevant on the display. The VT is now ready to receive (refer to
Software Manual for transfer procedure). The MemoCARD appears if
the Memory Card has been inserted in the VT (see Page 23-18)
