CHAPTER 36
Operation of terminal with keyboard
405.1200.037.2 - Rel.: 2.21 of 25/02/2008
36-10
VT50
info-messages
Format:
• Two rows of 20 characters for the text of the message.
Example with two messages.
When you press the next message is displayed
When you press the first message is displayed again:
VT60
info-messages
Format:
• Four rows of 20 characters for the text of the message.
Example with two messages.
When you press the next message is displayed:
When you press the first message is displayed again.
Pressure exceeds
safety limit
First message
Info
Water level lower
than work threshold
Second message
Help
Pressure exceeds
safety limit
First message
Pressure exceeds
safety limit
First message
F2
Water level lower
than work threshold
Second message
F1
