ESA VT50 - Kuhnke Plc; Lg Plc

CHAPTER 41
Connection cables
405.1200.037.2 - Rel.: 2.21 of 25/02/2008
41-52
KUHNKE PLC
LG PLC
RxD
TxD
RTS
CTS
GND
3
2
7
25
TxD
RxD
GND
2
3
20
25
7
4
5
15
18
DTR
+5V
VT side
D-Sub
25 pin male
PLC side
D-Sub
25 pin male
Max. 15 m.
Order code:
CVPLC32502
DL 305 DCU
(RS232)
(See “Chapter 41 -> Connecting the cable shield“)
RxD
TxD
RTS
CTS
GND
3
2
7
25
TxD
RxD
GND
2
3
5
4
5
15
18
VT side (Active)
D-Sub
25 pin male
PLC side
D-Sub
9 pin male
Max. 15 m.
Order code:
CVPLC07602
KUBES
(RS232)
(See “Chapter 41 -> Connecting the cable shield“)
RxD
TxD
RTS
CTS
GND
3
2
7
25
TxD
RxD
GND
3
2
5
4
5
15
18
VT side
D-Sub
25 pin male
PLC side
D-Sub
9 pin male
Order code:
CVPLC21102
K30 / K500 /K1000
(RS232)
(See “Chapter 41 -> Connecting the cable shield“)
Max. 15 m.
