ESA VT50 - Page 933

405.1200.037.2 - Rel.: 2.21 of 25/02/2008
41-53
RxD
TxD
RTS
CTS
GND
3
2
7
25
TxD
RxD
GND
2
3
5
4
5
15
18
VT side
D-Sub
25 pin male
PLC side
D-Sub
9 pin male
Order code:
CVPLC21202
K10
(RS232)
The 9 pin male Db must be connected to the GOLDSTAR cable of the K10 PLC.
(See “Chapter 41 -> Connecting the cable shield“)
Max. 15 m.
16
18
470 Ω
1/4 W
15
4
5
RTS
CTS
7
25
GND
TxRx-
22
10
TxRx+
220 Ω
1/4 W
7
470 Ω
1/4 W
TxRx-
GND
TxRx+
SHD
VT side
D-Sub
25 pin male
PLC side
terminals
Order code:
CVPLC21302
Series MK
(RS485)
(See “Chapter 41 -> Connecting the cable shield“)
RxD
TxD
RTS
CTS
GND
3
2
7
25
TxD2
RxD2
SG
7
4
5
4
5
15
18
VT side
D-Sub
25 pin male
PLC side
D-Sub
9 pin male
Order code:
CVPLC21402
Master K1205
(RS232)
Dip-Switch:
1 -> OFF (ROM MODE)
2 -> ON (BUILT-IN CNET)
(See “Chapter 41 -> Connecting the cable shield“)
Max. 15 m.
