CHAPTER 16
Video terminal VT505H
405.1200.037.2 - Rel.: 2.21 of 25/02/2008
16-12
For VT mounting instructions see “Chapter 30 -> Mounting the terminal
within the container“
.
Where accessories need to be fixed in or onto the VT terminal, you
are advised to do this before securing the VT to its container.
Accessories Any accessories should be mounted in accordance with the instructions in
the relevant chapter (see
“Chapter 34 -> Video terminal accessories“).
Connection
cable
The terminal is provided with a 10m long (AWG24) 25x0.25mmq shielded
cable already attached (see
“Chapter 33 -> Connection cable for H Series
terminals“
).
Adjusting
holding strap
for grip
The strap can be altered to adjust the grip for different hand sizes. To alter
strap:
• Open the leather cover
• Detach the strap ends
• Adjust the holding strap length
• Secure strap ends again
• Close leather cover
Calibration of
Touch Screen
The screen of VT505H is made of resistive, sensitive glass; for this type of
glass to work properly it requires a calibration procedure (the terminal is
already calibrated when supplied), that is, the resistive area of the glass
has to be adjusted to the visible are of the display.
Should it be thought necessary to repeat the calibration procedure this can
be done by following the instructions set out below.
The procedure must be carried out with great care as the preci-
sion of the keys area depends on the calibration.
