CHAPTER 37
Operation of terminal with touch screen
405.1200.037.2 - Rel.: 2.21 of 25/02/2008
37-34
To explain the way the help messages work, it is necessary to divide them
into two categories: on the one hand messages related to alarms and to
information messages, on the other hand help messages related to pages.
Help and
information
messages
relating to
alarms
If, when you are in a context of displaying alarms or information messages,
there is a help message present, the word HELP appears. If you touch the
alarm or the message accompanying the word HELP the help messaage is
displayed. Touching the ESC on the screen takes you back to the previ-
ous screenful.
The length of the message can be:
• VT155W -> up to 34 (characters) x 16 (rows)
• VT155W Vertical -> up to 21 (characters) x 24 (rows)
• VT185W -> up to 34 (characters) x 16 (rows)
• VT185W Vertical -> up to 21 (characters) x 24 (rows)
• VT505H -> up to 34 (characters) x 16 (rows)
• VT505W -> up to 34 (characters) x 16 (rows)
• VT515W -> up to 34 (characters) x 16 (rows)
• VT525H -> up to 34 (characters) x 16 (rows)
• VT525W -> up to 34 (characters) x 16 (rows)
• VT555W -> up to 34 (characters) x 16 (rows)
• VT56xW -> up to 34 (characters) x 16 (rows)
• VT575W -> up to 74 (characters) x 16 (rows)
• VT580W -> up to 74 (characters) x 16 (rows)
• VT585W -> up to 74 (characters) x 16 (rows)
• VT585WB -> up to 74 (characters) x 16 (rows)
• VT595W -> up to 93 (characters) x 16 (rows)
