Example of implementation of VTHCB board.
Memory card
This is a removable device in which you can store the information con-
tained in the VT terminal.
The Memory Card (Flash EPROM type) can be used:
• as a backup for the project and firmware
• to load one or more terminals without using a PC
• to send the end-user updates (without VTWIN)
VTHCB
F1
F2
F3
F4
F5
F9
F10
F8
F7
F6
Internal
swirtchboard
circuit
