ESA VT50 - Indramat Drive; Lenze Drive

405.1200.037.2 - Rel.: 2.21 of 25/02/2008
41-19
INDRAMAT DRIVE
LENZE DRIVE
RxD
TxD
RTS
CTS
GND
3
2
7
25
TD
RD
SG
2
3
7
4
5
15
18
VT side
D-Sub
25 pin male
Order code:
NOT CODED
PCCR0-GP1
(RS232)
SERIAL PORT 1 connection requires no parametrization, while the TYPE param-
eter like ASCII HOST needs to be set for SERIAL PORT 2. The MODE parameter
must be set as RS232.
(See “Chapter 41 -> Connecting the cable shield“)
Drive side
D-Sub
15 pin male
Max. 12 m.
16
18
470 Ω
1/4 W
15
4
5
RTS
CTS
7
25
GND
TxRx-
22
4RS485+
10
TxRx+
5RS485-
220 Ω
1/4 W
7
470 Ω
1/4 W
VCC
VT side
D-Sub
25 pin male
Order code:
NOT CODED
PCCR0-GP1
(RS485)
SERIAL PORT 1 connection requires no parametrization, while the TYPE param-
eter like ASCII HOST needs to be set for SERIAL PORT 2. The MODE parameter
must be set as RS485.
(See “Chapter 41 -> Connecting the cable shield“)
Drive side
D-Sub
9 pin male
16
18
470 Ω
1/4 W
15
4
5
RTS
CTS
7
25
GND
TxRx-
22
10
TxRx+
220 Ω
1/4 W
7
470 Ω
1/4 W
TxRx-
(A) 72
TxRx+
(B) 71
SHD
88
VT side
D-Sub
25 pin male
Order code:
NOT CODED
Series 82x
(RS485)
(See “Chapter 41 -> Connecting the cable shield“)
Drive side
Terminals
