CHAPTER 5
Video terminal VT130W
405.1200.037.2 - Rel.: 2.21 of 25/02/2008
5-14
Preparation
for reception
The program VTWIN (see Software Manual) must be used for the transfer,
but the terminal must be set up to receive. This means carrying out the fol-
lowing steps:
• Check that the VT is off
• Check that there is a serial connection between the PC and the VT
• Switch on the VT; when the message [WAIT FOR BOOT FORCED] is
displayed, press , or with the VT on press together + ; in
either case wait a moment
• The function to press depends on which port you intend to use (MSP,
ASP or MPI).
Transfer using MPI protocol:
• Proceed from the preceding mask; the following mask appears
Press F2 function to set MPI address, press F3 function to return to pre-
vious mask. Press F1 function if you intend to start the transfer.
Trasfer using ASP or MSP port:
• Proceed from the preceding mask; the following mask appears
Enter
Shift
Enter
VT130W TRANSFER PAGE
BOOT/RAM check: OK
FIRMWARE check: OK
--- DOWNLOADER MENU ---
F1:ASP F2:MSP
F3:MPI F4:EXIT
VT130W TRANSFER PAGE
BOOT/RAM check: OK
FIRMWARE check: OK
--- DOWNLOADER MENU ---
F1:TRANSF F2:CONFIG
F3:BACK
