CHAPTER 34
Video terminal accessories
405.1200.037.2 - Rel.: 2.21 of 25/02/2008
34-42
The above illustrations refer to VT320W; the procedure is basi-
cally the same for all those products that can be fixed to the back
cover (see Page 34-2).
20 key serial
keyboard
The following table lists the principal technical characteristics of the prod-
uct in question.
Keyboard
Non-customizable function keys --
Customizable function keys 20
Function key LEDs 20
Alphanumeric keys --
Operational keys --
Operational key LEDs --
Diagnostic LEDs --
Technical data
Power supply --
Power absorbed at 24Vdc --
Protection level IP65 (front-end)
Operating temperature 0..50°C
Storage and transportation temperature -20..+60°C
Humidity (non-condensing) 85%
Weight 550gr
Dimensions
External W x H x D [mm] 148 x188 x 27
Cut-out W x H [mm] 114 x 174
