405.1200.037.2 - Rel.: 2.21 of 25/02/2008
14-21
and wait a moment, or, using the appropriate button (see Page 14-24),
till the VT displays the following mask
• Choose the port you intend to use for the transfer (MSP or ASP); touch
the relevant on the display. The following mask will appear
• Choose the required transfer mode: MODEM if you intend to use a
modem or PC if you intend to use a serial port; touch the relevant on
the display
If the choose made is PC, the VT is ready to receive (see Software Manual
for transfer), if, on the other hand, you choose MODEM, the following
VT155W TRANSFER PAGE
Main BOOT and RAM check : OK
Main FIRMWARE check : OK
SELECT:
MSP ASP EXIT
VT155W TRANSFER PAGE
Main BOOT and RAM check : OK
Main FIRMWARE check : OK
SELECT:
REMOTE LOCAL EXIT
