The cable in the above figure, together with the relevant adapters, can be
used for all serial port connections of the VT. Below we list the adapters
and the combinations necessary for the various connections.
CVCOM25F9M
CVAD259
PC side
25 to 9 pins
CVAD2515CVAD259
CVCOM25F9M
CVAD25M9M
CVAD25M9M
CVCOM25F8M
CVCOM25F8M
VT side
25 to 9 pins
MODEM side
25 to 9 pins
VT side
25 to 15 pins
CVAD2515
VT side
25 to 8 pins
