CHAPTER 16
Video terminal VT505H
405.1200.037.2 - Rel.: 2.21 of 25/02/2008
16-4
Maximum tension 30Vdc
Maximum/minimum current 500mA/5mA
Conforms to the following standard(s)
IEC 60947-5-1, EN 60947-5-1, JIS C8201-5-1, UL-508, CSA 22.2. No. 14
Approval(s)
ISO12100/EN292, IEC60204-1/EN60204-1,
ISO11161/prEN11161, ISO10218/EN775, ANSI/RIA R15.06
Technical data
Power supply 24Vdc (18..32Vdc)
Power absorbed at 24Vdc 10W
Protection fuse Self-resetting
Protection level (Certificated) IP65
Operating temperature 0..50°C
Storage and transportation temperature -20..+60°C
Humidity (non-condensing) <85%
Weight (with cable length 10m) 3000gr
Dimensions
External W x H x D [mm] See on Page 34-8
Cut-out W x H [mm] --
Certification
Certifications and approvals CE
