ESA VT50 - Page 449

405.1200.037.2 - Rel.: 2.21 of 25/02/2008
23-3
User memory ▼▼▼▼
Project [Bytes] 192K + 832K (Text + Graphics)
●●●●
Data memory [Bytes] 128K (With back-up battery)
●●●●
Memory for Windows ® -based fonts [Byte] 128K
●●●●
Memory Card for backup 4Mb
●●●●
Memory Card for expansion --
Interfaces
MSP (Multi-serial port) RS232/RS422/RS485/TTY-20mA
●●●●
ASP (Auxiliary serial port) RS232/RS485
●●●●
ASP-15L (Auxiliary serial port) RS232/RS485
ASP-8 (Auxiliary serial port) RS232
ASP-9 (Auxiliary serial port) RS232
LPT parallel port Centronics
●●
Auxiliary port Connections for accessories
Accessories
Connectable accessories See table ”Chapter 34”
●●●●
Clock
Clock Hardware (With back-up battery)
●●●●
Networks
Integrated
Profibus-DP
CAN Open (Optoisolated interface)
Ethernet 10/100Mbit RJ45
Universal Bus Connector --
Optional See table ”Chapter 34”
●●●●
Proprietary networks
ESA-Net
Network server
●●●●
Network client
●●●●
Technical data
Power supply 24Vdc (18..32Vdc)
Power absorbed at 24Vdc 15W
Protection fuse Ø5x20mm - 800mA Quick Blow F
Protection level IP65 (front-end)
Operating temperature 0..50°C
Storage and transportation temperature -20..+60°C
Humidity (non-condensing) <85%
Weight 1400gr
Dimensions
External W x H x D [mm] 210 x 158 x 54
Cut-out W x H [mm] 198 x 148
Certification
Certifications and approvals CE, cULus, NEMA12
Code of terminal Characteristics of the terminal
VT565W A0000
VT565W AP000
VT565W A0M00
VT565W APM00
