405.1200.037.2 - Rel.: 2.21 of 25/02/2008
4-3
Interfaces ▼▼
MSP (Multi-serial port) RS232/RS422/RS485/TTY-20mA
●
ASP (Auxiliary serial port) RS232/RS485
ASP-15L (Auxiliary serial port) RS232/RS485
ASP-8 (Auxiliary serial port) RS232
●
ASP-9 (Auxiliary serial port) RS232
LPT parallel port Centronics
Auxiliary port Connection for accessory devices
Accessories
Connectable accessories See table ”Chapter 34”
●
Clock
Clock
Networks
Integrated
Profibus-DP
CAN Open (Optoisolated interface)
●
Ethernet 10/100Mbit RJ45
Universal Bus Connector --
Optional See table ”Chapter 34”
●
Proprietary networks
ESA-Net
Network server
Network client
●
Technical data
Power supply 24Vdc (18..32Vdc)
Power absorbed at 24Vdc 5W
Protection fuse Ø5x20mm - 315mA Quick Blow F
Protection level IP65 (front-end)
Operating temperature 0..50°C
Storage and transportation temperature -20..+60°C
Humidity (non-condensing) <85%
Weight 500gr
Dimensions
External W x H x D [mm] 166 x 86 x 41
Cut-out W x H [mm] 157 x 77
Certification
Certifications and approvals CE, RINA, DNV, cULus, NEMA12
Code of terminal Characteristics of the terminal
VT060 00000
VT060 000CN
