CHAPTER 4
Video terminal VT60
405.1200.037.2 - Rel.: 2.21 of 25/02/2008
4-6
Lines
Lists of bitmap images
Lists of texts
●
Local configuration of E-keys
Local configuration of F-keys
●
Macro field
4 x pages
Macros (Total/Commands x macro)
Message field
Message help
128
●
Multilanguage texts
4 Langs.
●
Object - Indicator
Object - Potentiometer knob
Object - Selector knob
Object - Sliding potentiometer
Object - Sliding selector
Page
127
●
Page help
127
●
Password
Pipelines (Number/Tot bytes)
Print
Print page (Total/Number of fields per page)
Programmable fonts
Project images
Public variables of ESANET network (Number/Total bytes)
Recipe field for recipe structure
Recipes (Number of variables per recipe)
Rectangles
Redefinable characters
7
●
Reports
Sequences - Random
64
●
Sequences - Start/stop
●
Static bitmaps
Symbolic field: Bit-group-structured dynamic bitmaps
Symbolic field: Single-bit-structured dynamic bitmaps
Symbolic field: Value-structured dynamic bitmaps
System messages
System variables assigned to recipe structure
Time long field
Time short field
Table 4.1: Functions and objects realizable with this VT (Part 3 of 4)
Code of terminal
VT060
✳✳✳✳✳
Objects/Functions Quantity ▼
Unless otherwise stated, there is no limit to the number of includable elements, only the size of project memory sets a limit.
*) indicative value determined by the dimensions of the project
