ECI Multi Functional Weighing Controller Operating Manual
Page 269
Case C (16 Bit, LSB to MSB)
BIT(s)
Function
0-2 (RW) (3bits)
Load Cell Type. 0: 2mV/V, 1: 2.5mV/V, 2: 5mV/V, 3: 10mV/V, 4: 20mV/V, 5: 160mV/V
3-4 (RW) (2bits)
Out of use
5 (/O)
1:Error, 0: No Error
6 (/O)
1: Calibration is possible, 0: No calibration is possible.
7 (/O)
Communication lock. 1:On 0:Off
8 (/O)
1:On device menu screen, 0: On Device main screen
9 (/O)
1: Absolute Zero yes, 0: Absolute Zero no
10 (/O)
1: Stagnancy, 0:Mobility
11 (/O)
1:Maximum load yes, 0: Maximum load no
12 (/O)
1:e2 zone
13 (/O)
1:e3 zone
14 (/O)
Out of use
15 (RW)
Measuring Type. 1:Multi Partition or Multi Interval, 0:Single Partition
(Y/O) Writable and Readable
(/O) Read Only
