ECI Multi Functional Weighing Controller Operating Manual
Page 270
14.4.1 Indication Program
Address
Word
Number
Function
0 (Y/O) 1
Command register: it is used for the special functions together with the Reg A and
Reg B.
1 (Y/O)
1
Reg A: General Purpose Data Register.
2 (Y/O)
1
Reg B: General Purpose Data Register.
5
1
Status A (Explanations are stated above in detail)
6
1
Status B (Explanations are stated above in detail)
7
1
Status C (Explanations are stated above in detail)
8 (/O)
2
Screen Value
10 (/O)
2
Tare Value
12 (/O)
2
Gross Value
16 (/O)
2
Tare Value (Internal Count)
20 (/O)
2
User Zero (Internal Count)
22 (/O)
2
Normalized Value (Factory Calibration has been made)
28 (/O)
2
Internal Count (Filtered)
30 (/O)
2
Internal Count (ADC)
38 (Y/O)
1
User Data Area 1
39 (Y/O)
1
User Data Area 2
