ECI Multi Functional Weighing Controller Operating Manual
Page 69
2) Accuracy: The filling weight is sent continuously during the filling.
(Baudrate is 9600bps)The format of the data string sent is same as the Speed mode
3) Detail: The information is sent in detail after the filling operation is over. (Baudrate is
9600bps).The format of the data string sent is as follows.
Meter TAB
Filling
Quantity
TAB Tare TAB Gross TAB Date TAB Time CR
3
Chr
9
1000
Chr
9
100
Chr
9
1100
Chr
9
16.04.2013
Chr
9
09:25:50 CR
Meter
Total number of filling. Resets when the product is changed or the device is restarted.
Filling
Quantity
Value of the Last Filling
Tare
The weight value on the weighing platform when the filling started
Gross
Sum of the filling quantity and the Tare value
Date
Date of the Last Filling
Time
Time of the Last Filling
