Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 41
Error Code
Item
Description
18-01
Error Message
No Film
Outline
Transfer film empty error (during initialization)
Detection Description
The printer detected the transfer film empty during initialization.
Remedy
[Related parts]
• Harnesses from the Film Beginning Sensor 2 (SN13) to the Main board
• Film Beginning Sensor 2 (SN13)
• Main board
[Remedy]
1. Check that the ink ribbon and transfer film are properly set.
2. Execute the sensor automatic adjustment in the sensor check mode
of the service mode (page 27).
3. Check/replace the related harness/cable, connector and parts.
18-02
Error Message
No Film
Outline
Transfer film empty error (during transfer operation)
Detection Description
The printer detected the transfer film empty during initialization.
Remedy
[Related parts]
• Harnesses from the Film Beginning Sensor 2 (SN13) to the Main board
• Film Beginning Sensor 2 (SN13)
• Main board
[Remedy]
1. Check that the ink ribbon and transfer film are properly set.
2. Execute the sensor automatic adjustment in the sensor check mode
of the service mode (page 27).
3. Check/replace the related harness/cable, connector and parts.
18-03
Error Message
No Film
Outline
Transfer film empty error
Detection Description
The printer detected the transfer film empty.
Remedy
[Related parts]
• Harnesses from the Film Beginning Sensor 2 (SN13) to the Main board
• Film Beginning Sensor 2 (SN13)
• Main board
[Remedy]
1. Check that the ink ribbon and transfer film are properly set.
2. Execute the sensor automatic adjustment in the sensor check mode
of the service mode (page 27).
3. Check/replace the related harness/cable, connector and parts.
19-01
19-02
Error Message
Film Wind up.
Outline
Transfer film wind up speed error (wind up axis)
Detection Description
The printer detected the wind-up speed error of the transfer film.
Remedy
[Related parts]
• Transfer Film Cassette
• Harnesses from the Film Feed Length Sensor (Wind Up Axis)
(SN14)/Film Supply Motor (DM4
) to the Main board
• Film Feed Length Sensor (Wind Up Axis) (SN14)/Film Supply Motor
(DM4)
• Main board
[Remedy]
1. Check the following items of the transfer film cassette.
⋅
There is no damage in the transfer film cassette.
⋅
There is no breakage or improper winding of the transfer film.
⋅
It is not empty.
⋅
The transfer film is properly set.
2. Check the reaction of the Film Feed Length Sensor (Wind Up Axis)
(SN14) in the sensor check mode of the service mode (page 27
).
3. Check the reaction of the Film Supply Motor (DM4) in the action check
mode of the service mode. If it is operating properly, clean the
transfer film feed roller.
4. Check/replace the related harness/cable, connector and parts.

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
