Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 46
21-XX
Error Message
Remove Card: flip
Outline
Reverse assembly card jam error
Detection Description
The printer detected a card jam at the Card Sensor (Cleaning Assembly Inlet)
(SN24) and the Card Sensor (Cleaning Assembly Outlet) (SN2).
Remedy
[Related parts]
• Harnesses from the Card Sensor (Cleaning Assembly Inlet) (SN24) to the Main
board
• Harnesses from the Card Sensor (Cleaning Assembly Outlet) (SN2) to the Main
board
• Harnesses from the Card Supply Motor (PM1) to the Main board
• Card Sensor (Cleaning Assembly Inlet) (SN24)
• Harnesses from the Card Sensor (Cleaning Assembly Outlet) (SN2) to the Main
board
• Card Supply Motor (PM1)
• Main board
[Remedy]
1. Check the card position at the jam error occurrence. If the card is delivered to
the cleaning roller, the Card Feed Motor (Reverse Assembly) (PM2
) may
indicate failure. Refer to error code 22-XX.
2. Check the reaction of the Card Sensor (Cleaning Assembly Inlet) (SN24) and
the Card Sensor (Cleaning Assembly Outlet) (SN2) in the sensor check mode
(page 27).
3. Check the reaction of the Card Supply Motor (PM1
) in the action check mode of
the service mode (page 27). If it is operating properly, clean the card supply
roller.
4. Check/replace the related harness/cable, connector and parts.
22-XX
Error Message
Remove Card: flip
Outline
Card supply assembly card jam error
Detection Description
The printer detected a card jam at the Card Sensor (Cleaning Assembly
Outlet) (SN2).
Remedy
[Related parts]
• Harnesses from the Card Sensor (Cleaning Assembly Outlet) (SN2) to
the Main board
• Harnesses from the Card Feed Motor (Reverse Assembly) (PM2) to
the Main board
• Harnesses from the Card Sensor (Cleaning Assembly Outlet) (SN2) to
the Main board
• Card Feed Motor (Reverse Assembly) (PM2)
• Main board
[Remedy]
1. Check the reaction of the Card Sensor (Cleaning Assembly Outlet)
(SN2) in the sensor check mode (page 27
).
2. Check the reaction of the Card Feed Motor (Reverse Assembly) (PM2)
in the action check mode of the service mode (page 27). If it is
operating properly, clean the cleaning roller and card feed roller.
3. Check/replace the related harness/cable, connector and parts.
23-XX
Error Message
Flip Card Jam
Outline
Reverse assembly card jam error
Detection Description
The printer detected a card jam at the Card Sensor (Reverse Assembly
Outlet) (SN3).
Remedy
[Related parts]
• Harnesses from the Card Sensor (Reverse Assembly Outlet) (SN3) to
the Main board
• Harnesses from the Card Feed Motor (Reverse Assembly) (PM2) to
the Main board
• Card Sensor (Reverse Assembly Outlet) (SN3)
• Card Feed Motor (Reverse Assembly) (PM2)
• Main board
[Remedy]
1.
Check the card position at the jam error occurrence. If the card is delivered to
the roller of the secondary transfer assembly, the Card Feed Motor (Secondary
Transfer Assembly) (HB1) may indicate failure. Refer to error code 30-XX.
2. Check the reaction of the Card Sensor (Reverse Assembly Outlet) (SN3) in the
sensor check mode (page 27).
3. Check the reaction of the Card Feed Motor (Reverse Assembly) (PM2) in the
action check mode of the service mode (page 27). If it is operating properly,
clean the card feed roller.
4. Check/replace the related harness/cable, connector and parts.

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
