Error Code
Item
Description
39-XX
Error Message
Remove Card: fdr
Outline
Card supply assembly card jam error
Detection Description
The printer detected a card jam at the Card Sensor (Cleaning Assembly Inlet)
(SN24) and the Card Sensor (Cleaning Assembly Outlet) (SN2).
Remedy
[Related parts]
• Harnesses from the Card Sensor (Cleaning Assembly Inlet) (SN24) to
the Main board
• Harnesses from the Card Sensor (Cleaning Assembly Outlet) (SN2) to
the Main board
• Harnesses from the Card Supply Motor (PM1) to the Main board
• Card Sensor (Cleaning Assembly Inlet) (SN24)
• Card Sensor (Cleaning Assembly Outlet) (SN2)
• Card Supply Motor (PM1)
• Main board
[Remedy]
1. Check the card position at the jam error occurrence. If the card is
delivered to the cleaning roller, the Card Feed Motor (Reverse
Assembly) (PM2
) may indicate failure. Refer to error code 22-XX.
2. Check the reaction of the Card Sensor (Cleaning Assembly Inlet)
(SN24) and the Card Sensor (Cleaning Assembly Outlet) (SN2
) in the
sensor check mode (page 27).
3. Check the reaction of the Card Supply Motor (PM1) in the action check
mode of the service mode (page 27). If it is operating properly, clean
the card supply roller.
4. Check/replace the related harness/cable, connector and parts.
3A-XX
Error Message
Remove Card: fdr
Outline
Card supply assembly card jam error
Detection Description
The printer detected a card jam at the Card Sensor (Cleaning Assembly
Outlet) (SN2).
Remedy
[Related parts]
• Harnesses from the Card Sensor (Cleaning Assembly Outlet) (SN2) to
the Main board
• Harnesses from the Card Feed Motor (Reverse Assembly) (PM2) to the
Main board
• Card Sensor (Cleaning Assembly Outlet) (SN2)
• Card Feed Motor (Reverse Assembly) (PM2)
• Main board
[Remedy]
1. Check the reaction of the Card Sensor (Cleaning Assembly Outlet)
(SN2
) in the sensor check mode
2. Check the reaction of the Card Feed Motor (Reverse Assembly) (PM2)
in the action check mode of the service mode (page 27). If it is
operating properly, clean the cleaning roller and card feed roller.
3. Check/replace the related harness/cable, connector and parts.
3B-XX
Error Message
Feeder Card Jam
Outline
Card supply assembly card delay jam error
Detection Description
The card did not reach the Card Sensor (Cleaning Assembly Inlet) (SN24).
Remedy
[Related parts]
• Harnesses from the Card Sensor (Cleaning Assembly Inlet) (SN24) to
the Main board
• Harnesses from the Card Supply Motor (PM1) to the Main board
• Card Sensor (Cleaning Assembly Inlet) (SN24)
• Card Supply Motor (PM1)
• Main board
[Remedy]
1. Check the reaction of the Card Sensor (Cleaning Assembly Inlet)
(SN24) in the sensor check mode (page 27
). Check the reaction of the
Card Supply Motor (PM1) in the action check mode of the service
mode (page 27). If it is operating properly, clean the card supply
roller.
2. Check/replace the related harness/cable, connector and parts.
