Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 61
Error code
Item
Description
64-01
Error Message
Call Tech Support
Outline
Thermistor temperature error
Detection Description
The heat roller thermistor (TM2) detected a temperature outside of the
controlled range.
Remedy
[Related parts]
• Harnesses from the Heat Roller Thermistor (TM2) to the Main board
• Heat Roller Thermistor (TM2) (Unit of replacement: Heat Roller)
• Main board
[Remedy]
1.
Check/replace the related harness/cable, connector and parts.
64-11
64-12
Error Message
Call Tech Support
Outline
Printhead thermistor temperature error
Detection Description
The printhead thermistor (TM5) detected a temperature outside of the
controlled range.
Remedy
[Related parts]
• Harnesses from the Printhead to the Main board
• Printhead
• Main board
[Remedy]
1. Check/replace the related harness/cable, connector and parts.
64-21
64-22
Error Message
Call Tech Support
Outline
Thermistor temperature error
Detection Description
The inner air thermistor (TM3) detected a temperature outside of the
controlled range.
Remedy
[Related parts]
• Harnesses from the Inner Air Thermistor (TM3) to the Main board
• Inner Air Thermistor (TM3)
• Main board
[Remedy]
1. Check/replace the related parts.
64-31
Error Message
Call Tech Support
Outline
Thermistor temperature error
Detection Description
The outer air thermistor (TM4) detected a temperature outside of the
controlled range.
Remedy
[Related parts]
• Harnesses from the Outer Air Thermistor (TM4) to the Main board
• Outer Air Thermistor (TM4)
• Main board
[Remedy]
1. Check/replace the related parts.
64-FF
Error Message
Call Tech Support
Outline
Board error (AD converter)
Detection Description
Access to the AD converter failed.
Remedy
[Related parts]
• Main board
[Remedy]
1. Check/replace the related parts.
65-XX
Error Message
Call Tech Support
Outline
Heat roller temperature error
Detection Description
Temperature adjustment of the heat roller failed.

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
