Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 62
Error Code
Item
Description
65-XX
Remedy
[Related parts]
• Harnesses from the Heat Roller to the Main board
• Heat Roller
• Main board
[Remedy]
1. Check/replace the related harness/cable, connector and parts.
67-XX
Error Message
Ribbon Key Err
Outline
ID-key communication error
Detection Description
ID-key communication is in an abnormal condition.
Remedy
[Related parts]
• Harnesses from the RFID PCB to the Main board
• RFID PCB
[Remedy]
1. Set ID-key properly.
2. Check/replace the related harness/cable, connector and parts.
68-XX
Error Message
Ribbon Key Empty
Outline
ID-key end detection
Detection Description
ID-key end is detected.
Remedy
[Related parts]
• Harnesses from the RFID PCB to the Main board
• RFID PCB
• Main board
[Remedy]
1. Replace with a new ID-key
2.
Check/replace the related harness/cable, connector and parts.
69-XX
6A-XX
6B-XX
Error Message
Ribbon Device Er
Outline
RFID PCB communication error
Detection Description
RFID PCB communication error is detected.
Remedy
[Related parts]
• Harnesses from the RFID PCB to the Main board
• RFID PCB
• Main board
[Remedy]
1.
Check/replace the related harness/cable, connector and parts.
6C-01
Error Message
Call Tech Support
Outline
Power supply off function error
Detection Description
The automatic power off failed.
Remedy
[Related parts]
• Harnesses from the Power Switch (SW1) to the Main board
• Power Switch (SW1
)
• Main board
[Remedy]
1. Check/replace the related harness/cable, connector and parts.
6D-XX
Error Message
Call Tech Support
Outline
Board error (DSP)
Detection Description
Access to the DSP failed.
Remedy
[Related parts]
• Main board
[Remedy]
1. Reinstall the firmware.
2. Check/replace the related parts.

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
