Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 60
Error Code
Item
Description
62-03
Error Message
Call Tech Support
Outline
Fan operation error
Detection Description
Operation error of the heat roller cooling fan was detected.
Remedy
[Related parts]
• Harnesses from the Heat Roller Cooling Fan (FAN3) to the Main board
• Heat Roller Cooling Fan (FAN3)
• Main board
[Remedy]
1. Check/replace the related harness/cable, connector and parts.
62-04
Error Message
Call Tech Support
Outline
Fan operation error
Detection Description
Operation error of the transfer film cooling fan was detected.
Remedy
[Related parts]
• Harnesses from the Transfer Film Cooling Fan (FAN4) to the Main
board
• Transfer Film Cooling Fan (FAN4)
• Main board
[Remedy]
1. Check/replace the related harness/cable, connector and parts.
63-01
Error Message
Call Tech Support
Outline
Sensor adjustment error
Detection Description
Sensor adjustment of the ribbon beginning sensor (SN9) failed.
Remedy
[Related parts]
• Harnesses from the Ribbon Beginning Sensor (SN9) to the Main
board
• Ribbon Beginning Sensor (SN9)
• Main board
[Remedy]
1. Check/replace the related harness/cable, connector and parts.
63-02
Error Message
Call Tech Support
Outline
Sensor adjustment error
Detection Description
Sensor adjustment of the film beginning sensor 1 (SN12) failed.
Remedy
[Related parts]
• Harnesses from the Film Beginning Sensor 1 (SN12) to the Main board
• Film Beginning Sensor 1 (SN12)
• Main board
[Remedy]
1. Check/replace the related harness/cable, connector and parts.
63-03
Error Message
Call Tech Support
Outline
Sensor adjustment error
Detection Description
Sensor adjustment of the film beginning sensor 2 (SN13) failed.
Remedy
[Related parts]
• Harnesses from the Film Beginning Sensor 2 (SN13) to the Main board
• Film Beginning Sensor 2 (SN13)
• Main board
[Remedy]
1. Check/replace the related harness/cable, connector and parts.

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
