Setup
Power Blazer 165
Modify Structure - EtherSAM
88260 100GE (4 Lanes) [103.125 Gbit/s] Port A1/A2/B1/B2 - QSFP28
Port A1/B1 - CFP4
100GE (2 Lanes) [106.25 Gbit/s]
100GE (1 Lane) [106.25 Gbit/s]
Port A1/A2/B1/B2 - QSFP28
40GE (4 Lanes) [41.25 Gbit/s] Port A1/A2/B1/B2 - QSFP28
25GE
10GE LAN
10GE WAN
1GE Optical
100M Optical
Port A1/A2/B1/B2 - SFP28
10/100/1000M Electrical Port A1/A2/B1/B2 - SFP28 (RJ45)
88460 400GE (8 Lanes) [425 Gbit/s] Port 1 - CFP8
Port 1 - QSFP56-DD
Port 1 - OSFP
400GE (4 Lanes) [425 Gbit/s] Port 1 - QSFP56-DD
Port 1 - OSFP
200GE (4 Lanes) [212.5 Gbit/s] Port 1 - QSFP56-DD
100GE (4 Lanes) [103.125 Gbit/s]
100GE (2 Lanes) [106.25 Gbit/s]
100GE (1 Lane) [106.25 Gbit/s]
Port 1 - QSFP56-DD
Port 1/2/3/4 - QSFP28
40GE (4 Lanes) [41.25 Gbit/s] Port 1/2/3/4 - QSFP28
25GE
10GE LAN
10GE WAN
1GE Optical
Port 1/2/3/4 - QSFP28 (with
adapter)
88480
88481
88482
400GE (8 Lanes) [425 Gbit/s]
400GE (4 Lanes) [425 Gbit/s]
Port 1/2 - QSFP-DD
Port 2 - OSFP
c
200GE (4 Lanes) [212.5 Gbit/s] Port 1/2 - QSFP-DD
100GE (4 Lanes) [103.125 Gbit/s]
100GE (2 Lanes) [106.25 Gbit/s]
100GE (1 Lane) [106.25 Gbit/s]
Port A1/A2 - QSFP28
a. Only available as a second port when the test application requires two ports.
b. Ethernet 10/100/1000M electrical is supported when using an active copper SFP.
c. When this port is available on the module.
Unit Interface/Rate Connector
