Setup
332 FTBx-88000 Series
MAC/IP/UDP
 Source EoE MAC Address indicates and allows changing (when the
Factory Default check box is cleared) the default EoE Media Access
Control (MAC) address. The default setting is 0E:01:00:xx:xx:xx.
 Destination EoE MAC Address allows entering the destination EoE
MAC address for the stream. The default setting is 0E:01:00:00:00:01.
 EoE VLAN
Note: Available when EoE VLAN is enabled; refer to Modify Frame Structure on
page 331.
VLAN ID allows selecting the VLAN ID: 0 through 4095 (default is 2).
Special VID values (IEEE Std 802.1Q-1998):
Priority allows selecting the VLAN priority: 0 (default) to 7:
Type allows selecting the EoE VLAN type: 0x8100, 0x88A8, 0x9100,
0xA100 (default), 0x9200, or 0x9300.
ID Description
0 The null VLAN ID. Indicates that the tag header contains only user priority
information; no VLAN identifier is present in the frame. This VID value must not
be configured as a PVID, configured in any Filtering Database entry, or used in
any Management operation.
1 The default PVID value used for classifying frames on ingress through a Bridge
Port. The PVID value can be changed on a per-Port basis.
4095 Reserved for implementation use. This VID value shall not be configured as a
PVID, configured in any Filtering Database entry, used in any Management
operation, or transmitted in a tag header.
0 000 - Low Priority 4 100 - High Priority
1 001 - Low Priority 5 101 - High Priority
2 010 - Low Priority 6 110 - High Priority
3 011 - Low Priority 7 111 - High Priority
