Setup
Power Blazer 331
MAC/IP/UDP
Service selection, available with EtherSAM, allows the configuration of
up to 10 services individually by either using the left/right arrow or by
tapping over the service numbers area then on a specific number.
Couple with Interface check box when selected (default) couples the
following settings with the interface (see Network on page 343) as
default configuration; changing any Network setting re-applies the
coupling process for that setting: Frame Format, Network Layer,
Source MAC Address, and all IP and VLAN
1
settings. The Source MAC
Address is always coupled when the Network Layer is set to IPv4 or
IPv6. Not available when using Provider Encapsulation.
Discovery, available with Traffic Gen & Mon for rates up to 25GE and
for 100GE (not supported at 100GE on 88200NGE), allows scanning the
remote interface to discover packet signatures that can be used for
stream configuration. Refer to Remote Interface Discovery on
page 1010.
Modify Frame Structure
Note: Refer to Modify Frame Structure on page 989.
Preamble/SFD
Preamble/SFD indicates that the frame structure contains the Preamble
and SFD.
EoE
Note: Available when EoE is selected as the Provider Encapsulation (see Modify
Frame Structure on page 331).
1. VLAN is not coupled for EtherSAM.
