Physical Interfaces and LEDs
Power Blazer 25
FTBx-88260 and Transceiver Systems
Transceiver
System
Port
Labelled
a
a. The ports are listed/referred as follows in the GUI: Port, FTBx-88260‘s port (A or B), transceiver system
port (1 or 2), and connector type; for example Port A1 - SFP28.
Description Supported Signal(s)
TA-SFP28
(two ports)
1
2
Optical IN/OUT port
SFP/SFP+/SFP28
transceiver
Ethernet 100/1000 Mbit/s, 10 Gbit/s, 25 Gbit/s optical
Ethernet 10/100/1000 Mbit/s electrical (using active
copper SFP)
Fibre Channel 1X, 2X, 4X, 8X, 10X, 16X, 32X
eCPRI 10 Gbit/s, 25 Gbit/s
CPRI 1.2, 2.4, 3.1, 4.9, 6.1, 9.8, 10.1, 24.3 Gbit/s
OBSAI 1.5, 3.1, 6.1 Gbit/s
OC-1/STM-0, OC-3/STM-1, OC-12/STM-4,
OC-48/STM-16, OC-192/STM-64
OTU1, OTU2, OTU1e, OTU2e, OTU1f, OTU2f
TA-QSFP28
(two ports)
1
2
Optical IN/OUT port
QSFP+ transceiver
Ethernet 40 Gbit/s
OTU3e2, OTU3e1, OTU3
Optical IN/OUT port
QSFP28 transceiver
Ethernet 50/100 Gbit/s
CPRI 9.8, 10.1, 24.3 Gbit/s
eCPRI 10/25/100 Gbit/s
OTU4
Optical IN/OUT port
QSFP56 transceiver
Ethernet 100 Gbit/s
TA-CFP4 1 CFP4 Ethernet 100 Gbit/s
OTU4
REF OUT REF OUT (SMA) Electrical port for eye diagram clock signal generation
TA-SYNC
b
and
TA-SYNC-
PREMIUM
b, c
b. Only one TA-SYNC / TA-SYNC PREMIUM transceiver system is supported per module. In case two TA-SYNC
are inserted, only one will be active, tap Setup, System, and the TA-Sync tab to see which one is active.
c. Provides the same functionalities as a TA-SYNC but with enhanced accuracy.
EXT CLK EXT CLK (SMB) IN: 2 MHz, 10 MHz, 1PPS
OUT: 2 MHz
1 PPS 1PPS (SMB) IN: 1PPS
d
d. Used for One-Way Latency measurement mode and Time Error / Wander test application.
ANTENNA ANTENNA (SMA) GNSS IN: Antenna for GNSS receiver
d
