Physical Interfaces and LEDs
28 FTBx-88000 Series
FTBx-88460 and Transceiver Systems
The following table shows the list of available ports and the supported
signals on the module excluding the TA4 transceiver system ports.
Port
Labelled
Description Supported Signal(s)
QSFP28
(P1, P2, P3, P4)
Optical IN/OUT port QSFP28
transceiver
Ethernet 1000 Mbit/s (optical)
a
, 10 Gbit/s
a
, 25 Gbit/s
a
,
40 Gbit/s, 50 Gbit/s, 100 Gbit/s
100G FlexO-1-RS
OTU4, OTU3e2, OTU3e1, OTU3, OTU2f, OTU1f, OTU2e,
OTU1e, OTU2, OTU1
a. Requires a QSFP28 to SFP28 transceiver adapter.
Optical IN/OUT port QSFP56
transceiver
Ethernet 100 Gbit/s
100G FlexO-1-RS
REF OUT Electrical port SMA for eye
diagram clock signal generation
EXT CLK Electrical port SMB for external
clock synchronization
1PPS
b
b. Available for One-Way Latency measurement mode.
