Setup
460 FTBx-88000 Series
Traces/PT - FlexO
SAPI OTU-TIM / SAPI ODU-TIM check box, when selected (cleared by
default), allows editing the expected Source Access Point Identifier and
also enables OTU/ODU-TIM alarm monitoring.
DAPI OTU-TIM / DAPI ODU-TIM check box, when selected (cleared by
default), allows editing the expected Destination Access Point Identifier
and also enables the OTU/ODU-TIM alarm monitoring.
PT / Global PT
Note: Global PT indicates that the PT settings apply to all Client ID.
Note: Changing the payload type (PT) does not alter the signal structure; it only
modifies the OH value that is generated.
Payload Type and Code allows the selection of the
generated/expected payload signal type either by selecting the payload
type from the list or by entering its code in hexadecimal (00 to FF).
Note: Codes not listed in the table are reserved for future standardization
(Reserved For International Standardization).
Payload type Hex Code
MSB
1234
LSB
5678
Reserved for International Standardization
a
00 0000 0000
Experimental mapping 01 0000 0001
Asynchronous CBR mapping 02 0000 0010
Bit Synchronous CBR mapping 03 0000 0011
ATM mapping 04 0000 0100
GFP mapping 05 0000 0101
Virtual Concatenation Signal 06 0000 0110
PCS Codeword Transparent Ethernet 07 0000 0111
FC-1200 into ODU2e 08 0000 1000
