CHAPTER 20
PAGE 19
PAGE DATE: 12. June 2015
MAINTENANCE MANUAL EXTRA 300LT
5 Inspect all removed items for damage prior to assembly.
Damaged items have to be replaced or if possible repaired
according to chapter 51.
N O T I C E In order to prevent the aircraft from nosing over the
assembly always has to start with the empennage.
6 Prior to assembly remove engine cowlings, canopy, main
fuselage cover including the rear support angle as per
chapters 51 and 53.
N O T E In contrast to the instructions given in the respective
chapters don‘t reinstall these items before completion
of the whole assembly.
7 Remove provisional attached rudder and vertical stabilizer
as per chapters 27 and 55.
8 Install horizontal stabilizer with elevator as per chapter 55.
The procedure described there is also applicable to the
installation of the complete horizontal tail. Remember to
connect the ground bonding lead of the elevator too.
9 Connect elevator push pull rod actuator lever as per chapter
27-00-01.
10 Connect trim wire to the tab actuator lever using fitted
clamp.
11 Inspect for full travel and elevator deflection in relation to
stick movement.
12 Inspect for full travel and trim tab deflection in relation to
trim switch activity.
13 Install the vertical stabilizer as per chapter 55.
14 Reinstall rudder to the vertical stabilizer as per chapter 27-
20-01.
15 Inspect for full travel and rudder deflection in relation to
rudder pedal movement.
16 Install the wing as per chapter 57.
17 Install navigation/strobe lights as per chapter 33-40-01.
18 Install propeller in accordance with MT-Propeller installa-
tion instructions E-124 latest revision.
