Foundry Networks FESX User Manual

Foundry Configuration Guide for the FESX, FSX, and FWSX
16 - 64 © Foundry Networks, Inc. December 2005
Displaying ARP Entries
You can display the ARP cache and the static ARP table. The ARP cache contains entries for devices attached to
the Layer 3 Switch. The static ARP table contains the user-configured ARP entries. An entry in the static ARP
table enters the ARP cache when the entry’s interface comes up.
The tables require separate display commands or Web management options.
Displaying the ARP Cache
To display the contents of the ARP cache, enter the following command at any CLI level:
Syntax: show arp [ethernet [<slotnum>/]<portnum> | mac-address <xxxx.xxxx.xxxx> [<mask>] | <ip-addr> [<ip-
mask>]] [<num>]
The <slotnum> parameter is required on chassis devices.
The <portnum> parameter lets you restrict the display to entries for a specific port.
The mac-address <xxxx.xxxx.xxxx> parameter lets you restrict the display to entries for a specific MAC address.
The <mask> parameter lets you specify a mask for the mac-address <xxxx.xxxx.xxxx> parameter, to display
entries for multiple MAC addresses. Specify the MAC address mask as “f”s and “0”s, where “f”s are significant
bits.
The <ip-addr> and <ip-mask> parameters let you restrict the display to entries for a specific IP address and
network mask. Specify the IP address masks in standard decimal mask format (for example, 255.255.0.0).
NOTE: The <ip-mask> parameter and <mask> parameter perform different operations. The <ip-mask>
parameter specifies the network mask for a specific IP address, whereas the <mask> parameter provides a filter
for displaying multiple MAC addresses that have specific values in common.
The <num> parameter lets you display the table beginning with a specific entry number.
NOTE: The entry numbers in the ARP cache are not related to the entry numbers for static ARP table entries.
FESX424 Router># show logging
Syslog logging: enabled (0 messages dropped, 0 flushes, 0 overruns)
Buffer logging: level ACDMEINW, 3 messages logged
level code: A=alert C=critical D=debugging M=emergency E=error
I=informational N=notification W=warning
Static Log Buffer:
Dec 15 19:04:14:A:Fan 1, fan on right connector, failed
Dynamic Log Buffer (50 entries):
Dec 15 18:46:17:I:Interface ethernet Lab2, state up
Dec 15 18:45:15:I:Warm start
FESX424 Router# show arp
Total number of ARP entries: 5
IP Address MAC Address Type Age Port
1 207.95.6.102 0800.5afc.ea21 Dynamic 0 6
2 207.95.6.18 00a0.24d2.04ed Dynamic 3 6
3 207.95.6.54 00a0.24ab.cd2b Dynamic 0 6
4 207.95.6.101 0800.207c.a7fa Dynamic 0 6
5 207.95.6.211 00c0.2638.ac9c Dynamic 0 6
