Foundry Networks Switch and Router User Manual

Policies and Filters
December 2000 C - 37
Figure C.8 OSPF redistribution filters
RIP Redistribution Filters
RIP redistribution filters control redistribution of routes from other protocols into RIP. A Foundry device running
RIP can redistribute static routes, OSPF routes, and BGP4 routes (if BGP4 is supported on the device) into RIP.
Optionally, you can specify a metric that the route must match or you can set the metric on redistributed routes.
By setting the metric, you can cause the router to prefer RIP routes or redistributed routes to the specified
network.
Actions
RIP redistribution filters permit (redistribute) or deny (do not redistribute) OSPF or BGP4 routes into RIP.
Scope
You configure RIP redistribution filters globally. They are automatically applied as soon as you configure them.
OSPF
Router
OSPF
Router
IP/RIP
Router
192.124.28.0/24
OSPF Route Redistribution Filters
FilterID Action Address
-------------------------------------------
1 Permit 201.99.81.0/24
2 Permit 192.124.28.0/24
201.99.81.0/24
191.47.12.0/24
X
